2 Stroke Petrol Engine Cut Section Model

Send Inquiry

Request To Call Back

2 Stroke Petrol Engine Cut Section Model

Name: 2 Stroke Petrol Engine Cut Section Model
Brand: Sami Lab Tek
Price: 17500.0 INR
Availability: InStock

Price 17500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

2 Stroke Petrol Engine Cut Section Model Specification

Control Type
Manual

Speed Range
Demonstration only

Temperature Resistance
Up to 80C (for acrylic section)

Display Type
Physical model, Not digital

Shape
Engine block with cut section and base

Glass Type
Acrylic/Perspex cut view window

Features
Hand-operated, Heavy base, Clearly visible engine components, Sectioned for educational demonstration

Accuracy
Representative, educational accuracy

Type
2 Stroke Petrol Engine Cut Section Model

Dimension (L*W*H)
Approx. 350mm x 250mm x 350mm

Equipment Type
Engine Model, Teaching Aid

Equipment Materials
Mild Steel, Aluminum Alloy, Acrylic/Perspex for cut section

Power
Manual demonstration (No power required)

Material
Metal body with powder coating, transparent acrylic

Application
Educational, Laboratory Equipment, Demonstration of Internal Combustion Engine Parts

Finish
Corrosion resistant paint

Model Operation
Hand cranked flywheel to simulate engine movement

Mounting
Mounted on sturdy metallic base plate

Color
Multi-color for part identification

Portability
Portable for easy classroom use

Educational Level
Suitable for schools, colleges, training institutes

Maintenance
Low, wipe clean with dry cloth

Parts Shown
Piston, Crankshaft, Cylinder, Spark Plug, Carburetor, Exhaust, and Intake ports

Weight
Approx. 7-10 kg

About 2 Stroke Petrol Engine Cut Section Model

2 Stroke Petrol Engine Cut Section Model Description

The 2 Stroke Petrol Engine Cut Section Model is an educational and demonstration model designed to clearly illustrate the construction and working of a two-stroke petrol engine. This model is carefully cut and sectioned to expose internal components such as the piston, cylinder, crankshaft, connecting rod, spark plug, transfer port, and exhaust port, enabling easy visualization and understanding.

The model demonstrates the working principle of a two-stroke engine, where the complete engine cycle is achieved in two strokes of the pistoncompression and power. It helps learners observe how air-fuel mixture enters the cylinder, gets compressed, ignites, and exhaust gases are expelled, all in a simplified and visible manner. The movement of parts can be shown either manually or through a motorized mechanism for smooth operation.

The cut section model is made from high-quality materials and mounted on a strong base frame to ensure durability and stability. Different parts are often painted in distinct colors to make identification easier for students during practical demonstrations.

Features

Clear display of internal engine components
Demonstrates complete 2-stroke engine cycle
Durable construction with long life
Easy to operate and maintain
Color-coded parts for better understanding

Applications

Widely used in engineering colleges, diploma institutes, ITI workshops, and technical training centers for teaching engine working principles and mechanical concepts.

Comprehensive Educational Tool

This engine model provides a tangible learning experience for students, clearly displaying significant internal components through an acrylic cut section. Its interactive hand crank demonstrates engine movement, making it an effective aid for explaining engine operation in classrooms and training environments.

Built for Durability and Safety

Manufactured with a metal body, powder coating, and acrylic or perspex windows, the model resists corrosion and high temperatures (up to 80C). Its sturdy metallic base ensures stability during demonstrations, and its portable design allows teachers to use it conveniently in various educational settings.

FAQ's of 2 Stroke Petrol Engine Cut Section Model:

Q: How does the hand-cranked flywheel simulate engine operation?

A: The hand-cranked flywheel physically moves internal engine components, such as the piston and crankshaft, allowing students to observe the mechanical process of a 2-stroke petrol engine in motion. This manual operation demonstrates the working principles without requiring power.

Q: What parts are visible in the cut section model?

A: The model exposes essential engine components, including the piston, crankshaft, cylinder, spark plug, carburetor, exhaust port, and intake port. These are clearly identified with multi-color finishes for easy educational reference.

Q: When is this model most beneficial in a teaching environment?

A: This model is most useful during lessons covering internal combustion engines, offering real-time, tactile demonstrations to help students visualize and comprehend engine mechanics.

Q: Where can this engine cut section model be used?

A: It is designed for use in school classrooms, college laboratories, and technical training institutes across India, providing a versatile teaching resource for educators and trainers.

Q: What is the process for maintaining this educational engine model?

A: Maintenance is minimal: simply wipe the surface with a dry cloth to keep the parts clean. Its corrosion-resistant finish and durable materials help ensure longevity even with regular use.

Q: How portable is the engine cut section model for classroom use?

A: Weighing approximately 7-10 kg and mounted on a stable base, the model remains sturdy yet portable, allowing easy movement between classrooms or laboratory workstations as required.
