Izod Charpy Impact Testing Machine

Price 150000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Izod Charpy Impact Testing Machine Specification

Release Mechanism
Electro-mechanical

Pendulum Weight
Up to 22 kg

Net Weight
Approx. 250 kg

Testing Standard
Conforms to IS, BS, ASTM, and other international standards

Energy Range
Up to 300 Joules

Automation Grade
Manual

Finish
Powder coated for corrosion resistance

Usage/Application
Impact Testing of Materials

Dimensions
Approx. 900 x 550 x 1050 mm

Resolution
1 Joule

Type
Izod Charpy Impact Testing Machine

Safety Features
Protective shielding and interlocks

Display Type
Analog

Specimen Size Accommodated
10 x 10 x 55 mm (Charpy), 10 x 10 x 75 mm (Izod)

Izod Charpy Impact Testing Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
7 Days

About Izod Charpy Impact Testing Machine

An Izod Charpy Impact Testing Machine is a precision material testing instrument used to determine the impact strength, toughness, and fracture behavior of metals, plastics, and composite materials under sudden loading conditions. It evaluates the energy absorbed by a specimen during fracture, helping industries ensure material reliability and safety in real-world applications.

This machine combines both Izod and Charpy test methods in a single unit, making it highly suitable for quality control laboratories, research institutions, engineering colleges, automobile industries, and material testing labs.

Key Features

Dual test system: Izod & Charpy impact testing in one machine
Heavy-duty rigid frame for vibration-free operation
High-precision pendulum mechanism for accurate results
Digital / analog display of impact energy
Interchangeable specimen supports for both test types
Safety guard enclosure for operator protection
Multiple energy range hammers available
Conforms to international standards (ASTM / ISO)

Working Principle

The machine operates on the pendulum impact principle, where a weighted hammer is released from a fixed height to strike a notched specimen. The difference between initial and remaining energy after fracture determines the impact strength of the material.

Charpy Test: Specimen is supported horizontally and struck at the center
Izod Test: Specimen is clamped vertically and struck above the notch

Applications

Metal and alloy testing (steel, aluminum, etc.)
Plastic and polymer impact resistance testing
Automotive and aerospace material evaluation
Construction material quality control
R&D laboratories and engineering institutes
Industrial production quality assurance

Advantages

Provides quick and reliable toughness evaluation
Helps detect brittle or weak materials before use
Suitable for both academic and industrial applications
Ensures compliance with quality standards
Cost-effective solution for dual testing needs

Technical Specifications (Typical)

Impact energy range: 5 J to 300 J (model dependent)
Pendulum speed: approx. 35 m/s
Specimen size: as per ASTM / ISO standards
Display: Digital or analog dial gauge
Operation: Manual / motorized release system

Versatile Compliance with Global Standards

This impact testing machine supports various international standards, including IS, BS, and ASTM, enabling consistent and recognized material evaluation. This flexibility makes it suitable for global and local manufacturers, suppliers, and researchers, ensuring their test methodologies meet industry benchmarks.

Safety-Focused and Durable Design

Operator security is prioritized with protective shielding and interlocks, reducing accident risks during high-energy impact tests. The powder-coated finish enhances corrosion resistance, contributing to the product's longevity even in challenging industrial environments.

Precision and Reliable Measurement

With a pendulum that can deliver up to 300 Joules of energy and a resolution of 1 Joule, this machine provides high accuracy in determining the toughness of various materials. Its manual, analog display allows for straightforward operation and dependable results, critical in quality control processes.

FAQ's of Izod Charpy Impact Testing Machine:

Q: How does the Izod Charpy Impact Testing Machine assess material impact strength?

A: The machine uses a swinging pendulum to strike standardized specimens, measuring the energy absorbed during fracture. This reveals the material's toughness and helps determine its suitability for various applications.

Q: What testing standards does this machine support?

A: It conforms to several international standards, such as IS, BS, and ASTM, making it suitable for a wide range of testing requirements both domestically and globally.

Q: When should I use the Izod Charpy Impact Testing Machine?

A: You should use this machine whenever you need to evaluate the impact resistance of materials, typically during research, product development, or quality assurance in manufacturing environments.

Q: Where can the Izod Charpy Impact Testing Machine be utilized?

A: It is ideal for quality control labs, research institutions, manufacturing units, and any facility needing standardized impact testing in India and beyond.

Q: What is the process for conducting a test with this machine?

A: A specimen is securely placed in the fixture, and the pendulum is positioned and released electro-mechanically. The analog display then shows the energy absorbed during the test, which is recorded for analysis.

Q: What benefits does this machine provide over other testing solutions?

A: It offers robust construction, reliable results, compliance with several standards, enhanced safety features, and corrosion resistance, ensuring consistent performance and operator safety.

Q: How does the safety mechanism work during an impact test?

A: The machine is equipped with protective shielding and interlocks that prevent accidental operation, ensuring maximum user protection throughout the testing process.
