Laboratory Water Bath

Name: Laboratory Water Bath
Brand: Sami Lab Tek
Price: 5500.0 INR
Availability: InStock

Price 5500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Laboratory Water Bath Specification

Temperature
Ambient to 99C

Frequency
50Hz

Equipment Type
Laboratory Water Bath

Resolution
0.1C

Response Time
Instantaneous for control

Number of Specimens
Varies with bath size (usually 6 or 12 holes)

Features
Thermostatic control, corrosion resistant, non-reactive inner chamber

Power Supply
230V AC, 50Hz

Display Type
Digital

Operating Voltage
230V AC

Mounting Type
Benchtop

Application
Heating of samples in laboratory, incubation, chemical reactions

Measuring Range
Ambient to 99C

Specimen Size
Depends on test tube slot diameter

Automation Grade
Semi-automatic / Manual

Accuracy
1C

Max Height
Approx. 20-25 cm

Interface Type
-

Usage
Laboratory sample heating

Capacity
6, 8, or 12 liters

Machine Weight
Approx. 8-12 kg (varies with capacity)

Control Mode
Digital temperature controller (thermostat)

Lid Type
Removable concentric ring or flat lid

Insulation
High-grade mineral wool or glass wool

Heating Element
Immersion heating element, corrosion-resistant

Water Level Indicator
Available in select models

Outer Body Material
Mild Steel with powder coating or stainless steel

Drain Valve
Provided for easy water removal

Inner Chamber Material
Stainless Steel (SS 304 / SS 316)

Safety Features
Over temperature protection, fuse cut-off

Voltage Fluctuation Protection
Yes

Laboratory Water Bath Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7 Days

Laboratory Water Bath About

A Laboratory Water Bath is a precision heating equipment designed to incubate and maintain samples at a constant temperature for extended periods. It consists of a stainless-steel chamber filled with water, heated by an integrated heating element and controlled through a digital or analog temperature controller.

Widely used in microbiology, biotechnology, pharmaceutical, and research laboratories, this equipment ensures uniform heat distribution and safe heating without direct flame exposure.

Key Features

Temperature range: Ambient +5C to 99C
High-precision thermostat / digital PID controller
Stainless steel inner chamber for corrosion resistance
Uniform temperature distribution for accurate results
Double-walled construction with insulation
Over-temperature protection and safety features
Available in multiple capacities (6L, 12L, 25L, etc.)

Working Principle

The water bath operates by heating water using an internal electric heater. The thermostat or digital controller regulates and maintains the desired temperature by switching the heater on and off automatically, ensuring stable and uniform heating conditions.

Applications

Incubation of samples
Warming reagents and media
Melting substrates
Bacteriological and microbiological testing
DNA/RNA and enzyme studies
Chemical reactions requiring controlled heating

Types Available

Digital Water Bath
Serological Water Bath
Circulating Water Bath
Shaking Water Bath

Advantages

Provides uniform and controlled heating
Safe for heating flammable substances (no open flame)
Easy to operate and maintain
Suitable for continuous laboratory use

Superior Build Quality for Lasting Performance

Engineered with premium materials, the inner chamber uses SS 304/SS 316 stainless steel, renowned for non-reactivity and corrosion resistance. The robust exterior, made from powder-coated mild steel or stainless steel, ensures structural longevity. Advanced insulation with high-grade mineral wool or glass wool drastically reduces heat loss and enhances energy efficiency.

Advanced Digital Temperature Control

A digital controller with a thermostat allows precise thermal management from ambient to 99C, supporting a range of laboratory applications. The digital display delivers instant readings with 0.1C resolution and 1C accuracy, ensuring reliable sample heating and consistent experiment results.

Comprehensive Safety and User Features

User safety and convenience are paramount. Over-temperature protection, fuse cut-off, and voltage fluctuation systems shield both the operator and samples. Additional features like a water level indicator (in select models), easy-drain valve, and removable lid make maintenance straightforward. The immersion heating element is corrosion-resistant, ensuring long operational life.

FAQ's of Laboratory Water Bath:

Q: How do I operate the laboratory water bath for optimal sample heating?

A: To use the water bath, fill it with water up to the indicated level, place test tubes or containers in the designated slots, and select your desired temperature using the digital temperature controller. The thermostat ensures precise heating from ambient to 99C. For best results, monitor water levels and use the removable lid to minimize evaporation.

Q: What safety features are included in this laboratory water bath?

A: The water bath is equipped with over-temperature protection, a fuse cut-off mechanism, and voltage fluctuation protection. These features guard against overheating and electrical instabilities, ensuring the safety of both users and laboratory samples during operation.

Q: When is this laboratory water bath most beneficial for laboratory applications?

A: This equipment is particularly beneficial whenever precise temperature control is required for sample incubation, chemical reactions, or other procedures. Its accuracy and range make it ideal for research, clinical, and quality control laboratories.

Q: Where can I use this laboratory water bath?

A: Designed as a benchtop unit, this water bath is suitable for placement in laboratories across educational institutions, research centers, clinical facilities, and industrial testing sites throughout India.

Q: What is the process for cleaning and maintaining the water bath?

A: Routine maintenance includes regularly draining and refilling the water using the supplied valve to prevent residues and scale. Periodically wipe the stainless steel inner chamber and check the immersion heating element for deposits. Always disconnect power before cleaning and avoid abrasive cleaners for long-term performance.

Q: How does the digital temperature controller enhance usability?

A: The controller ensures fast and precise temperature adjustments, featuring instantaneous response and stable thermal conditions. The easy-to-read digital display helps monitor the setting and actual temperature at a glance, facilitating efficient lab workflows.

Q: What are the benefits of the corrosion-resistant stainless steel inner chamber?

A: The non-reactive SS 304/SS 316 inner chamber resists corrosion from prolonged exposure to water and chemicals, maintaining cleanliness and preventing sample contamination, thereby extending the lifespan of the equipment.
