Digital Mortar Cube Vibrating Machine

Name: Digital Mortar Cube Vibrating Machine
Brand: Sami Lab Tek
Price: 30000.0 INR
Availability: InStock

Price 30000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Digital Mortar Cube Vibrating Machine Specification

Measuring Range
Preset vibration cycle

Frequency
50 Hz

Interface Type
Push Button Control

Power Supply
230 V AC, 50 Hz

Equipment Type
Mortar Cube Vibrator

Mounting Type
Table Top

Automation Grade
Semi-automatic

Application
Compacting mortar specimens for strength testing

Accuracy
2% of set frequency

Display Type
Digital LED display

Number of Specimens
Up to 3 specimens

Features
Sturdy construction, automatic preset timer, consistent vibration, low maintenance

Max Height
Approx. 425 mm

Operating Voltage
230 V AC

Resolution
Digital

Response Time
Immediate

Specimen Size
70.6 mm cube

Test Range
Standard Mortar Mix

Humidity
Up to 90% RH

Temperature
5C to 40C

Usage
Laboratory and field tests

Capacity
Up to 3 mortar cubes

Machine Weight
Approx. 60 kg

Test Speed
12000 400 vibrations per minute

Control Mode
Digital Control

Timer
Digital timer, programmable (up to 99 minutes)

Sound Level
Less than 75 dB

Body Material
Mild Steel, powder coated

Motor Power
1/4 HP

Vibration Mode
Consistent, uniform vibration across specimens

Safety Feature
Overload protection, safety guard

Tray Material
Cast iron

About Digital Mortar Cube Vibrating Machine

The Digital Mortar Cube Vibrating Machine is a precision laboratory equipment used for compacting cement mortar cubes in moulds to achieve uniform density and eliminate air voids. It is widely used in construction material testing laboratories for preparing standard mortar specimens for compressive strength testing.

This machine is equipped with a digital control panel that allows accurate setting of vibration time and ensures consistent performance across multiple test cycles. The controlled vibration helps in achieving proper compaction of mortar cubes as per standard testing requirements.

Constructed with a heavy-duty steel frame and high-performance vibration system, the Digital Mortar Cube Vibrating Machine ensures durability, stability, and reliable operation. It is designed for long-term laboratory use with minimal maintenance.

Key Features:

Digital timer control for precise vibration duration
High-efficiency vibration system for uniform compaction
Strong and rigid steel body construction
Suitable for standard 70.6 mm mortar cube moulds
Easy-to-operate control panel
Low maintenance and long service life
Ensures consistent and repeatable test results

Applications:

Cement and mortar testing laboratories
Civil engineering quality control departments
Construction material testing facilities
Academic and research institutions
Infrastructure development projects

Working Principle:

The machine generates controlled vibrations through an electric motor, which compact mortar inside cube moulds. The digital timer ensures accurate vibration duration, resulting in uniform density and reliable strength test specimens.

Precision Compaction for Mortar Testing

Achieve uniform and repeatable mortar cube samples with consistent vibration across specimens. The digital timer allows programmable cycles up to 99 minutes, and preset vibration ensures optimal compaction for strength evaluation. This automation minimizes human error and enhances test reliability.

User-Friendly Digital Operation

Ease of use is at the forefront with a digital LED display and push button interface. The machine's immediate response time enables quick setup and monitoring. Designed for table top mounting, it is suitable for both laboratory and on-site field work.

Durability and Safety Assured

Constructed from sturdy, powder-coated mild steel with a cast iron tray, this machine offers low maintenance and long service life. Built-in overload protection and a safety guard maximize operator safety during every use.

FAQ's of Digital Mortar Cube Vibrating Machine:

Q: How does the Digital Mortar Cube Vibrating Machine ensure consistent vibration for specimens?

A: The machine delivers a consistent, uniform vibration across all specimens via a powerful 1/4 HP motor operating at 12,000 400 vibrations per minute. Its digital control maintains preset parameters, ensuring reproducible compaction results for up to three mortar cubes at once.

Q: What are the main benefits of using this machine for mortar strength testing?

A: Key benefits include precise compaction via programmable timers, automatic vibration for accuracy, built-in safety features (overload protection, safety guard), digital operation for ease of use, low maintenance, and reliable performance in both field and laboratory environments.

Q: Where can the Digital Mortar Cube Vibrating Machine be used?

A: Designed for versatility, it is suitable for both laboratory and field test environments. The compact, table-top mounting and sturdy construction support its use by manufacturers, service providers, suppliers, and traders who require standardized mortar cube compaction.

Q: How do you operate the machine for compacting mortar cubes?

A: To operate, load up to three 70.6 mm mortar cubes into the cast iron tray, set the desired time on the digital timer (up to 99 minutes), and start the test using the push button controls. The machine will apply preset, uniform vibration, and stop automatically at the end of the cycle.

Q: What safety features are included in this mortar cube vibrator?

A: The machine is equipped with an overload protection system to prevent motor stress, a safety guard for user protection during operation, and robust construction to further safeguard against accidental harm.

Q: What is the process and accuracy level for a typical test?

A: The process involves placing the specimens, programming the timer, and starting the vibration cycle. The digital control ensures the preset cycle is delivered with an accuracy of within 2% of the set frequency, and digital resolution provides precise monitoring throughout the test.
