Tile Flexural Testing Machine

Tile Flexural Testing Machine About

The Tile Flexural Testing Machine is a precision laboratory equipment used for determining the flexural strength (modulus of rupture) of ceramic tiles, concrete tiles, and paving blocks. It is widely used in construction material testing laboratories and quality control departments to ensure the durability and performance of tiles under bending loads.

This machine is designed with a rigid load frame and a high-accuracy loading system that applies controlled force on the tile specimen until failure occurs. The load is measured using a calibrated load cell or proving ring system, ensuring accurate and repeatable results as per standard testing procedures.

Built with a heavy-duty steel structure and corrosion-resistant components, the Tile Flexural Testing Machine ensures stability, durability, and long-term operational reliability. It is suitable for continuous laboratory use with minimal maintenance requirements.

Key Features:

• High-precision load measurement system
• Rigid and vibration-free steel frame
• Suitable for ceramic tiles, concrete tiles, and pavers
• Uniform and controlled loading application
• Digital/analog load display options available
• Durable and low-maintenance design

Applications:

• Ceramic and tile manufacturing industries
• Construction material testing laboratories
• Civil engineering quality control departments
• R&D laboratories for building materials
• Infrastructure and flooring product testing

Working Principle:

The machine applies a gradually increasing load at the center of a supported tile specimen until it breaks. The maximum load at failure is used to calculate the flexural strength of the tile.

Precision Testing for Tiles and Ceramics

This machine is purpose-built for measuring the bending strength of tiles and various ceramics. With a capacity of 5 kN or 10 kN and compatibility for specimens up to 400 mm wide, it facilitates reliable testing in compliance with globally recognized standards. Its intuitive controls enable accurate measurements in research, manufacturing, and quality control.


Robust and User-Friendly Design

Constructed from heavy-duty mild steel, the equipment boasts a stable floor-standing mount and a protective powder-coated finish to ensure longevity in demanding environments. Features such as overload protection, an emergency stop button, and a digital display exemplify its focus on operator safety and ease of use.
